RFS Omni Anten I-ATO5-698/3800M MHz
RFS Omni Anten I-ATO5-698/3800M MHz
RFS Omni Anten I-ATO5-698/3800M MHz
Teknik Özellikler
|
General Specifications
|
| Product Type |
|
Omnidirectional Antenna |
| Techn. Application |
|
Indoor |
|
|
Mechanical Specifications
|
| Number of Input Ports |
|
2 |
| Connectors |
|
N female |
| Connector Cable |
mm (in) |
300 (11.8) |
| Height (Less Connectors) |
mm (in) |
18 (0.7) |
| Width (Less Connectors) |
mm (in) |
140 (5.5) |
| Length (Less Connectors) |
mm (in) |
290 (11.4) |
| Weight |
kg (lb) |
0.4 (0.18) |
|
|
Electrical Specifications
|
| Frequenz |
MHz |
698-960 |
1427-1710 |
1710-2700 |
3400-3800 |
| Gain, typ |
dBi |
2.5 |
4.0 |
4.5 |
5.0 |
| VSWR |
|
1.8 |
1.8 |
1.8 |
1.8 |
| Impedance, Ohm |
Ω |
50 |
| Polarization |
|
2x linear |
| Intermodulation (IM3) |
|
-153 dBc (2 x 43dBm) |
| Total Input Power max. |
W |
50 |
|
|
Material
|
| Radome Material |
|
ABS |
| Radome Color |
|
White ( RAL 9003 ) |
|
|
Temperature Specifications
|
| Operation Temperature |
°C (°F) |
-40 to 55 (-40 to 131 ) |
|
|
Testing and Environmental
|
| Environmental Class |
|
Indoor |
|
