RFS 15dB Directional Coupler 694/3800 MHz 7/16 Female
RFS 15dB Directional Coupler 694/3800 MHz Frekans Aralığında 7/16 Female Konnektör
RFS 15dB Directional Coupler 694/3800 MHz 7/16 Female
Teknik Özellikler
|
Structure
|
| Product Type |
|
Directional Coupler |
| Techn. Application |
|
Indoor |
| Number of Input Ports |
|
1 |
| Number of Output Ports |
|
2 |
| Connector Type |
|
7/16 female |
|
|
Electrical Specifications
|
| Frequency Range |
MHz |
694 – 3800 |
| Impedance |
Ohm |
50 |
| Insertion Loss max. |
dB |
0.4 |
| Max. VSWR / Return Loss |
VSWR/dB |
1.25/19.1 (1.25) |
| Intermodulation (IM3) |
|
-155 dBc with 2×43 dBm tones |
| Coupling Value |
dB |
15 |
| Directivity min. |
dB |
20 |
| Coupling Flatness max. |
dB |
±1.0 |
| Total Input Power |
W |
200 |
|
|
Temperature Specifications
|
| Temperature Range |
°C (°F) |
-25 to +65 (-13 to +149) |
|
|
Mechanical Specifications
|
| Height |
mm (in) |
16.5 (0.65) |
| Width |
mm (in) |
63.2 (2.49) |
| Length |
mm (in) |
159.4 (6.28) |
| Weight |
kg (lb) |
0.25 (0.55) |
|
|
Testing and Environmental
|
| Environmental Class |
|
IP65 |
|
