RFS 10dB Directional Coupler 694/3800 MHz 7/16 Female

RFS 10dB Directional Coupler 694/3800 MHz 7/16 Female

RFS 10dB Directional Coupler 694/3800 MHz Frekans Aralığında 7/16 Female Konnektör

Kategoriler: ,

RFS 10dB Directional Coupler 694/3800 MHz 7/16 Female

Teknik Özellikler



Structure


Product Type Directional Coupler
Techn. Application Indoor
Number of Input Ports 1
Number of Output Ports 2
Connector Type 7/16 female


Electrical Specifications


Frequency Range MHz 694 – 3800
Impedance Ohm 50
Insertion Loss max. dB 0.7
Max. VSWR / Return Loss VSWR/dB 1.25/19.1 (1.25)
Intermodulation (IM3) -155 dBc with 2×43 dBm tones
Coupling Value dB 10
Directivity min. dB 20
Coupling Flatness max. dB ±1.0
Total Input Power W 200


Temperature Specifications


Temperature Range °C (°F) -25 to +65 (-13 to +149)


Mechanical Specifications


Height mm (in) 18 (0.71)
Width mm (in) 58.2 (2.3)
Length mm (in) 159.4 (6.28)
Weight kg (lb) 0.24 (0.53)


Testing and Environmental


Environmental Class IP65
