RFS Tapper 8dB 694/3800 MHz 7/16 Female

Teknik Özellikler



Structure



Product Type Unequal Divider/Tapper
Techn. Application Indoor
Number of Input Ports 1
Number of Output Ports 2
Connector Type 7/16 female


Electrical Specifications



Frequency Range MHz 694 – 3800
Impedance Ohm 50
Insertion Loss max. dB 0.8
Max. VSWR / Return Loss VSWR/dB 1.30/17.7 (1.3)
Intermodulation (IM3) 160dBc (2x43dBm)
Coupling Value dB 8.5
Coupling Flatness max. dB +1.0 / -2.0
Power Ratio – between Outputs dB 6:1 / 8dB
Total Input Power W 200


Temperature Specifications



Temperature Range °C (°F) -25 to +65 (-13 to +149)


Mechanical Specifications



Height mm (in) 49.7 (1.96)
Width mm (in) 19.5 (0.77)
Length mm (in) 84.3 (3.32)
Weight kg (lb) 0.32 (0.71)


Testing and Environmental



Environmental Class IP65
